GINGIVA

• Tear resistance gingival masks
• Flexible and easy to trim
• Produced under ISO standarts 13485:2016
• Find here validated DLP, LCD 3D printers list

Material PropertiesValueStandardTensile strength2.2 MpaASTM D638Flexural strength1.1 MpaASTM D790-02Elongation at Break24.5%ASTM D638Shore Hardness81 AASTM D2240Density1.104 g/cm3 at 23 CASTM D1475Viscosity1145 mPa.s at 23 CDIN 53211-4ColorPink

1- Washing

After the printing is completed, wash the part as attached to the building plate with ethyl alcohol (>%90) or isopropyl alcohol (>%90) for 5 minutes. Make sure that alcohol covers the part entirely when washing. Do not over-wash, it may cause deterioration in dimensions of the part.

2- Drying

Use air-compressor to dry the washed part. Make sure that the part is dry and uncured resin is cleaned up completely. If there is still uncured resin left on the part, wash it with fresh alcohol and dry again.

3- Part Removal

Remove the printed part from the build plate using a scraping tool. Be very careful not to damage the model.

4- Post Curing

Post curing application does not significantly affect the Gingiva resin's mechanical properties. However, post-curing helps to remove the stickiness on the printed pieces; thus, the following process is suggested for easy use: 10 minutes with MEDIFIVE curing chamber at 3rd-degree light intensity Otoflash curing recommendations 1000 flashes without gas.

Store the PowerResins Temp bottle in dark and moisture free place at room temperature (20-24 °C).

Do not forget shaking the resin well before use.

If your printer has heater, you can set the temperature at 32 °C. Otherwise, you can heat your resin in a microwave for 18 seconds or by submerging in hot water for 15-20 minutes.
