PowerResinEu

Surgical Guide

Surgical Guide

$239.99 USD
$239.99 USD
Sale Sold out
Weight



Autoclavable, Rigid Surgical Guide Resin

PowerResins SG resin is a transparent CE certified Class Ia biocompatible, autoclavable with standart protocols, clear and rigid surgical guide resin perfectly formulated for guided implant surgeries. 3D printing with exceptional mechanical properties provides you the best full arch multi unit implant guides cost effectively. Easy to insert drill sleeves directly after printing. Perfectly can be used as gingivectomy guides and bone reduction guides.


  • High flexural strength and modulus guided surgeries
  • Transparent, odorless and tasteless
  • Can be sterilized via autoclave at 121-125 degrees celsius
  • Produced under ISO standards 13485:2016
  • Find here validated 3D printers list

If you're using a third-party printer without a built-in heater, we recommend preheating the resin to 37°C for optimal results.

Disclaimer: All orders shipped outside the United States are subject to import taxes, duties, and fees, which are the responsibility of the customer. Please ensure you are aware of and prepared to cover any applicable import costs when placing an international order.



View full details

Product Description

Product Features

  • High flexural strength and modulus guided surgeries
  • Transparent, odorless and tasteless
  • Can be sterilized via autoclave at 121-125 degrees celsius
  • Produced under ISO standarts 13485:2016
  • Find here validated 3D printers list

Material Properties

Material PropertiesValueStandardTensile strength41.1 MpaASTM D638Flexural strength104.2 MpaASTM D790-02Flexural modulus2800 MpaASTM D790-02Density1.1 g/cm3 at 23 CASTM D1475Shore Hardness83.6 DASTM D2240Viscosity520-540 mPa.s at 23 CDIN 53211-4ColorTranslucent White

Post Process

1- Washing

After the printing is completed, wash the part as attached to the building plate with ethyl alcohol (>%90) or isopropyl alcohol (>%90) for 5 minutes. Make sure that alcohol covers the part entirely when washing. Since the Surgical Guide resin is biocompatible never wash it with the alcohol used for other resins before. Use a brush to remove uncured resin if needed. Do not over-wash, it may cause deterioration in dimensions of the part.

2- Drying

Use air-compressor to dry the washed part. Make sure that the part is dry and uncured resin is cleaned up completely. If there is still uncured resin left on the part, wash it with fresh alcohol and dry again.

3- Part Removal

Remove the printed part from the build plate using a scraping tool. Be very careful not to damage the model.

4- Post Curing

Supports should be removed from the model cautiously and insert drills before curing. 20 minutes with MEDIFIVE curing chamber at 3rd-degree light intensity Otoflash curing recommendations 104 MPa flexural strength with 5000 flashes without gas.

Storage Conditions

Store the PowerResins SG bottle in dark and moisture free place at room temperature (20-24 °C).

Do not forget shaking the resin well before use.

If your printer has a heater, you can set the temperature at 32 °C. Otherwise, you can heat your resin by submerging in hot water for 15-20 minutes.

  • BIOCOMPATIBLE

    Produced from biocompatible raw material used in dental applications.

  • PRECISION DRILLING

    Specially developed for performing precise surgical implant procedures.

  • PRESSURE RESISTANT

    Resistant to high pressure, suitable for surgical implant guide.

  • SAFE & NO TASTE

    Safe to handle. Does not contain any hazardous solvent or dangerous monomers.
